Gr1 Gr2 Titanium Blind Flange ANSI B16.5 50mm with 150#-2500# Pressure Rating

Brand Name : LH-Ti

Model Number : LH-BL

Certification : ISO9001, TUV etc.

Place of Origin : Baoji, China

MOQ : 1 piece

Price : US dollar $30/pc--US dollar $80/pc

Payment Terms : L/C,T/T,Western Union

Supply Ability : 5000 pcs per month

Delivery Time : 3-15 work days

Packaging Details : Wrapped by foam contained in plywood box for export

Product name : Ansi titanium blind flange

Standard : ANSI B16.5

Material : gr2, gr7, gr12

Application : Chemical industry

Sealing surface : RF

Size : NPS 1/2 - NPS 24(DN 10 - 2000)

Pressure : 150#-2500#

Surface : Polished

Technique : Froged and CNC Machined

Inspection : Ultrasonic Testing & Material Test Report EN10204.3.1

Contact Now

Gr1 Gr2 Titanium Flange ANSI B16.5 ASME B16.5 Titanium 50mm

Titanium flange is a part made of non-ferrous titanium or titanium alloy to make pipes and pipes connected to each other, connected to the pipe end. It can be cast, threaded or welded. The flange connection is composed of a pair of flanges, a gasket and a number of bolts and nuts. The gasket is placed between the sealing surface of the two flanges. After tightening the nut, the specific pressure on the surface of the gasket will be deformed after reaching a certain value, and the uneven part of the sealing surface will be filled, so that the connection is tight and not leaking. The common grades: TA0 TA1, TA2, TA3, TA9, TA10, TC4, etc

Chemical requirements

N C H Fe O Al V Pd Mo Ni Ti
Gr1 0.03 0.08 0.015 0.20 0.18 / / / / / bal
Gr2 0.03 0.08 0.015 0.30 0.25 / / / / / bal
Gr5 0.05 0.08 0.015 0.40 0.20 5.5~6.75 3.5~4.5 / / / bal
Gr7 0.03 0.08 0.015 0.30 0.25 / / 0.12~0.25 / / bal
Gr12 0.03 0.08 0.015 0.30 0.25 / / / 0.2~0.4 0.6~0.9 bal
Tensile requirements
Grade Tensile srength(min) Yeild strength(mm) Elongation(%)

KSI MPa Ksi MPa
1 35 240 20 138 24
2 50 345 40 275 20
5 130 895 120 828 10
7 50 345 40 275 20
12 70 438 50 345 18

Product picture:

Gr1 Gr2 Titanium Blind Flange ANSI B16.5 50mm with 150#-2500# Pressure Rating
